Ford Transit Turbos by Generation
The first tab shows the full Transit list, including the Transit Connect. The next two split the big Transit by generation.
For other Ford vans and cars, go to our Ford turbo page.
Built Around Working Vans
Ford Transit Turbo Codes by Engine
The Transit has used five diesel engine sizes since 2000. Front-wheel drive and rear-wheel drive vans with the same engine size can still need different turbos.
| Generation | Engine | Turbo Codes |
|---|---|---|
| Mk6 (2000 to 2006) | 2.0 Di, TDdi and TDCi | 726194-5005S, 802419-5005S, 709035-5005S, 802419-5004S, 714467-5014S |
| Mk6 (2000 to 2006) | 2.4 TDdi and TDCi | 49135-06030, 49135-06035, 49135-06115, 49135-06017, 49135-06020, 49135-06025, 49135-06000, 49135-06037 |
| Mk7 (2006 to 2014) | 2.2 TDCi | 49131-05313, 49131-05300, 767933-5015S, 753519-5009S, 786880-5021S, 786880-5019S, 787556-5022S |
| Mk7 (2006 to 2014) | 2.4 TDCi | 49131-05400, 752610-5032S, 49131-06400 |
| Mk7 (2006 to 2014) | 3.2 TDCi | 779366-5002S, 773098-5008S, 853333-5001S |
| Mk8 (2014 on) | 2.0 EcoBlue | 838452-5002S, 838417-5002S, 850840-5007S, 850841-5010S, 852072 |
| Transit Connect | 1.5, 1.6 and 1.8 TDCi | 758532-5019S, 802419-5008S, 819872-5001, 49172-03000 |
Transit Turbo Prices
Transit turbo prices start at £200 and reach about £1,200.
For a working van, a reconditioned turbo holds the repair bill down. You pay less than the new price for a unit rebuilt to the same quality.
Turbo Options for Your Transit
One quality standard covers all four options, so the decision is about budget.
Reconditioned Exchange
The most popular choice for older Mk6 and Mk7 vans.
Remanufactured
A full rebuild with new internals for vans still doing big miles.
New
Brand-new aftermarket build, no exchange required.
New OEM
OEM-grade parts for newer EcoBlue vans.
Not sure which replacement turbo makes sense for your van? Ask our team.

Front-Drive or Rear-Drive, We Check
The 2.2 TDCi Transit was built in both front-wheel and rear-wheel drive versions, and each uses a different turbo. The same is true of other Transit engines. We confirm the drive type before quoting, so the turbo we send matches your van.
Searching for a specific turbo? Explore our shop today
Need help choosing a turbo? Contact us for assistance
Speak With Our Team About Your Transit
Running a fleet or need several units? Contact our team for a quote. The Ford Transit Custom turbo page covers the mid-size van, and our Ford turbo hub links to cars and pickups too.
Ford Transit Turbo FAQs
A rear-wheel drive Transit has a propshaft running back to the rear axle, which you can see from underneath. The registration or the VIN plate will also confirm it.
No. The Connect is a smaller van with smaller engines and its own turbos.
Yes. We can quote for multiple units, which suits fleets and garages buying in bulk.
